LDR-U72S UHF RFID Reader
LDR-U72S UHF RFID Reader
Katrangan singkat:
Item No.:LDR-U72S
Rincian cepet
This device is an Android rugged mobile computer. It features powerful processor, 10000mAh battery and superb UHF RFID capability. That it can read tags in bulk from long ousing, fleet management and etc.
LDR-U72S UHF RFID Reader
| Product appearance | |||
| Jinis | Detail | Standard configuration | Optional |
| produk | Dimensions | 178x83x17mm | NA |
| Weight | 580g | NA | |
| Color | Black (bottom shell black, front shell black) | ||
| LCD | Display size | 5.0#(Select 5.72#full screen） | NA |
| Display resolution | 1280*720/ 5.2” IPS LTPS 1440 x 720 | NA | |
| TP | Touch Panel | Multi-touch panel, Corning grade 3 glass toughened screen | NA |
| Camera | Front camera | 5.0MP(optional） | NA |
| Rear camera | 13MP Autofocus with flash | NA | |
| Speaker | Built-in | Built-in 8Ω/0.8W waterproof horn x 1 | NA |
| Microphone | Built-in | Sensitivity: -42db, Output impedance 2.2kΩ | NA |
| Jinis | Removable polymer lithium ion battery | NA | |
| Battery | Capacity | 3.7V/10000mAh | NA |
| Battery life | About 8 hours (standby time > 300h) | NA | |
| System Hardware Configuration | |||
| Jinis | Detail | Description | Optional |
| CPU | Jinis | MTK 6763- Octa-core | NA |
| Speed | 2.0GHz | NA | |
| RAM | Memory | 3GB (2G or 4G optional) | NA |
| ROM | Storage | 32GB (16G or 64G optional) | NA |
| Operating System | Operating System Version | Android 12 | |
| NFC | Built-in | Support ISO/IEC 14443A protocol, card reading distance: 3-5cm | HF |
| Network connection | |||
| Jinis | Detail | Description | Optional |
| WIFI | WIFI module | WIFI 802.11 b/g/n/a/ac frequency 2.4G+5G dual band WIFI, | NA |
| Bluetooth | Built-in | BT5.0(BLE) | NA |
| 2G/3G/4G | Built-in | CMCC 4M： LTE B1,B3,B5,B7,B8,B20,B38,B39,B40,B41 WCDMA 1/2/5/8 GSM 2/3/5/8 | NA |
| GPS | Built-in | Nyokong | NA |
| Data Collection | |||
| Jinis | Detail | Description | Optional |
Fingerprint | Optional | Fingerprint module: capacitive USB press module | |
| Image size：256*360pi xei；FBI PIV FAP10 certification； | |||
| Image resolution：508dpi | |||
| International standard： | |||
| Authoritative certification： | |||
| Acquisition speed: single frame image acquisition time ≤0.25s | |||
QR code | Optional | Honeywell 6603&zebra se4710&CM60 | |
| Optical resolution: 5mil | |||
| Scanning speed: 50 times/s | |||
| Support code type: PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse Maxicode,QR Code, MicroQR, QR Inverse,Aztec,Aztec Inverses,Han Xin,Han Xin Inverse | |||
RFID function | Low frequency | Support 125k and 134.2k, effective recognition distance 3-5cm | Optional |
| High frequency | 13.56Mhz，support 14443A/B;15693 agreement，effective recognition distance3-5cm | Optional | |
UHF | CHN frequency：920-925Mhz | Optional | |
| US frequency：902-928Mhz | |||
| EU frequency：865-868Mhz | |||
| Protocol standard：EPC C1 GEN2/ISO18000-6C | |||
| Antenna parameter：spiral antenna（4dbi） | |||
| Card reading distance: according to different labels, the effective distance is 8~25m | |||
| Reliability | |||
| Jinis | Detail | Description | Optional |
2G/3G/4G | Drop height | 150cm, Power on status | |
| Operating Temp. | -20 °C to 50 °C | ||
| Storage Temp. | -20 °C to 60 °C | ||
| Tumble Specification | Six side rolling test up to 1000 times | ||
| Humidity | Humidity: 95% Non-Condensing | ||
ya wis, ukuran bisa selaras miturut requirement customer, lan indifferent dawa lan jembaré.
ya wis, kita seneng banget ngirim sawetara conto saiki kanggo referensi sampeyan. Sampel gratis, sampeyan mung kudu nangani biaya pangiriman.
ya wis, sampeyan bisa milih materi lan chip apa sing arep.
Minimal order 500-1000 pcs.
ya wis, kirim file ing format "AI." utawa "CDR" kanthi "garis gedhe" menyang email.
Kasunyatane yaiku warna sing ditampilake ing monitor sing kita deleng lan warna sing dicithak ing produk nyata duwe beda. Kanggo efek kualitas paling apik, sampeyan bisa nyedhiyani kita sampel match utawa nemtokake werna Pantone. We cocog werna liwat 90% sing luwih dhuwur tinimbang rata-rata industri 80%
Iku gumantung ing cara pengiriman milih, tag putih, Biasane, tags bakal dikirim metu ing 7 ~ 15 dina sawise pembayaran rampung.
Urutan jaminan perdagangan dianjurake. Platform Alibaba bakal nglindhungi pesenan saka pambayaran nganti pangiriman, utawa dening T / T, Paypal lan liya-liyane.
ya wis, kita nyedhiyani jaminan kualitas kanggo 1 taun, kajaba karusakan fisik.
